Choosing the right motor for an industrial power tool is no trivial task. Designers must consider the unique operating profile of the tool as well as operating life, product weight, user comfort and energy efficiency – particularly if the tool is to be battery operated.
Thomas Baile, Business Development Manager at Portescap, examines the performance requirements of power tool applications and looks at how the latest advances in motor technology for these tasks are helping to address typical design compromises.
So often in product design there are conflicting operational requirements. The industrial power tool is a typical example, with an operating profile that is quite different from other motor-driven applications. Whether the specific tool is fastening, gripping or cutting, there is a specific motion profile that is split into two phases.
First there is the speed phase, where there is little resistance – perhaps as bolts thread in or as the jaws of a cutting or gripping tool approach the workpiece. During this phase, a motor that operates at a faster free-run speed reduces cycle time and boosts productivity.
Then there is the torque phase, as the tool performs the more forceful work of tightening, cutting or gripping and the need for torque becomes paramount. A motor that delivers high peak torque can perform a wider range of tough jobs without excessive heating.
These alternating speed and torque cycles must be constantly repeated in demanding industrial applications. The different speed, torque and duration characteristics complicate the motor selection process, calling for a design that minimises losses to achieve the best solution possible. This is even more critical for battery operated tools, where only limited power is available yet where the design engineer wants to be able to achieve the maximum number of operations from a single charge.
Given these conflicting requirements, it might seem that there is no ideal solution. The electrical performance of a motor is defined by the magnetic circuit, so every option requires a compromise. The first component within the circuit, the magnet, has a fixed value. However, the second component, the copper winding, can be easily modified: by changing both the wire diameter and the number of turns, the torque constant (Kt) and resistance (R) can be fine-tuned.
In the speed phase of the industrial power tool’s operation profile, the motor needs to run fast with little resistance. Here, a lower Kt value gives increased speed. During the torque phase, however, the motor is expected to deliver peak torque at low speeds. A higher Kt value gives a higher output torque at a given current. Here we have conflict.
We might think to select a low Kt value to increase speed, and compensate the low Kt with more current to reach higher output torque. However, a higher current would increase the copper losses, generating heat and thus limiting the maximum torque available. Excess heat impacts on the comfort of the user, while the increased current impacts on battery life.
There are also iron losses to consider, which are related to speed. Eddy current losses increase with the square of speed, heating up the motors simply when rotating – even in a no-load condition.
Motors optimised for power tool applications
There is no unique solution, and in the past design engineers would have had to accept the performance compromise in the different phases of operation and in the broader utilisation requirements for the tool. However, Portescap has developed a new range of brushless slotless motors optimised for use in power tools that go a long way to minimising the traditional design compromise.
Brushless motors have inherent advantages over brushed motors in power tool designs. Brushless motors are less susceptible to mechanical wear (no brush friction), can be operated at much higher speeds (shortening cycle time and increasing productivity) and can sustain high peak current (no brushes) – for example during the tightening phase of a fastening tool’s operation – providing far greater life in the hand tool.
In terms of power density, a brushless slotless motor is a better option than slotted, providing superior ability to maintain speed under load. Further, while the slotted motor can handle higher temperatures to allow for more torque generation, this is not of direct benefit to industrial power tool applications. Heat is the enemy in the industrial power tool mostly hand-held: leading to the battery being drained more quickly and reducing user comfort and safety.
The latest development from Portescap represents a significant evolution of the brushless slotless motor, specifically for industrial power tool applications. The new Ultra EC™ family of brushless slotless motors employs a revolutionary and patented U coil technology. These miniature motors contain a winding that is parallel to the motor axis, unlike the skewed arrangement of a conventional slotless motor, perpendicular magnetic forces are minimised, reducing copper losses and enabling the motor to develop more power.
Iron losses at high speed in slotless motors are already greatly reduced compared with slotted designs. With this new straight winding, Ultra EC motors have a shorter rotor length which allows for a lower rotor inertia and further reduced iron losses. This revolutionary new design optimises speed and torque in a compact package for the most challenging applications.
With these new products, Portescap has gone a long way to eliminating the compromises design engineers have traditionally faced in selecting motors for industrial power tools. Fasteners, grippers and cutting tools can all benefit from this increased performance, lower weight and greater energy-efficiency.
Image Captions:
Image 1 + 2: When choosing the right motor for an industrial power tool, designers must consider the unique operating profile of the tool as well as operating life, product weight, user comfort and energy efficiency.
Image 3: The Ultra EC family of brushless slotless motors employs a revolutionary and patented U coil technology.
Image 4: Ultra EC brushless slotless motors containt a winding that is parallel to the motor axis so perpendicular magnetic forces are minimised, reducing coper losses and enabling the motor to develop more power.
Image 5: Typical working cycles for industrial power tools repeated continually.
