The shear strength of structural blind fasteners is generated by the combined resistance against failure of the pin and sleeve. This takes place along the joint shear line between fastened plates.
The tensile strength of structural blind fasteners differs to that of LockBolts, as they form a blind side positive lock either by bulbing or expanding of the sleeve. The sleeve, assisted by the permanently secured pin, therefore resists failure along its centre line.
1. Bulbing The sleeve of the fastener is compressed, causing it to fold outwards to form a bulb. This forms itself tightly against the joint material. Once the pin is permanently locked into place the pintail will break off, completing the installation.
2. Expanding Pulling on the pintail causes the head of the pin to draw into the sleeve. This expansion causes a foot print to form against the joint material.
Note: The pre-load of blind rivets is generally not published, as it varies widely depending on the application.
To find out more about Huck’s wide range of Blind Fasteners, watch this video
