Kollmorgen’s PMX series hybrid steppers added to Heason's motor range

Updates

Kollmorgen’s PMX series hybrid stepper motors are available through Heason. They are claimed to provide a comprehensive solution for uncomplicated open-loop motion control. With six NEMA frame sizes from 08 to 34, each with several stack-length options, the PMX can deliver holding torque from 2.8Ncm to 11.4Nm with maximum speeds to 3000rpm. Numerous standard options include bipolar and unipolar windings, integral connectors, shaft flats and keyways, rear shafts, IP65 sealing and more.

NEMA sized 08, 11 and 14 hybrid stepper motors have been added to Kollmorgen’s range for the first time as standard products. The smallest motor, the PMX08, has a nominal square size of just over 20mm and length of only 30mm.

International approvals and standards including CE, RoHS, and REACH compliance apply throughout the PMX series. The series is supported with a range of compatible stepper drives and single or multi-axis motion controls from simple step and direction models to high performance EtherCAT and CANopen networked variants.
